Cryogenic Rubber Foam is a reliable and effective solution for insulation in extreme cold environments. Its versatility, durability, and insulation properties make it a top choice for a wide range of industrial and commercial applications.
Fewer joints ensure the air tightness of the system and make the installation efficient.
Comprehensive cost is highly competitive.
Built-in moisture proof design eliminates the need to install an extra moisture barrier.
Free from fiber, dust, CFC, and HCFC.
No expansion joint is required during application.
One of the key features of Cryogenic Rubber Foam is its exceptional insulation properties. Its closed-cell structure helps to prevent the transfer of heat, making it an ideal choice for use in cryogenic tanks, pipelines, and other cold storage applications.
Dimension Details
Inches
mm
Size (L * W)
㎡ / Roll
3/4"
20
10 × 1
10
1"
25
8 × 1
8
Property
Base Material
Test Method
ULT Grade
LT Grade
Thermal Conductivity
-100°C: 0.028 -165°C: 0.021
0°C: 0.033 -50°C: 0.028
ASTM C177
Density Range
60-80 Kg/m³
40-60 Kg/m³
ASTM D1622
Recommend Operation Temperature
-200°C to 125°C
-50°C to 105°C
-
Percentage Of Close Areas
> 95%
> 95%
ASTM D2856
Moisture Performance Factor
N/A
< 1.96x10 g(m.m.Pa)
ASTM E 96
Wet resistance Factor μ
N/A
> 10000
EN12086 EN13469
Water Vapor Permeability Coefficient
N/A
0.0039g/h.m² (25mm thickness)
ASTM E 96
PH Value
≥ 8.0
≥ 8.0
ASTM C871
Tensile Strength (Mpa)
-100°C: 0.30 -165°C: 0.25
0°C: 0.15 -50°C: 0.218
ASTM D1623
Compressive Strength (Mpa)
-100°C: ≤ 0.3
-40°C: ≤ 0.16
ASTM D1621
Frequently Asked Questions
What are the insulation properties of Cryogenic Rubber Foam?
Cryogenic Rubber Foam offers exceptional insulation performance. Its closed-cell structure (exceeding 95%) prevents heat transfer, making it ideal for deep cold environments such as cryogenic tanks, pipelines, and storage applications.
What is the recommended operating temperature range?
The recommended operating temperature depends on the material grade. The ULT Grade operates efficiently from -200°C to 125°C, while the LT Grade is suitable for temperatures from -50°C to 105°C.
Does this cryogenic foam require an additional moisture barrier?
No, it features a built-in moisture-proof structure. This design effectively prevents moisture penetration, saving both installation time and material costs without requiring an extra moisture barrier.
Is the insulation safe and environment-friendly?
Yes, the material is manufactured without fibers, dust, CFC, or HCFC, ensuring clean installations and compliance with safety and environmental protection guidelines.
What sizing and dimensions are standard?
The foam is available in rolls. Common dimensions include 3/4" (20mm) thickness sizing at 10m x 1m (10㎡/roll) and 1" (25mm) thickness sizing at 8m x 1m (8㎡/roll).
