Kingflex
Kingflex
| Kingflex Dimension | |||
|---|---|---|---|
| Inches | mm | Size (L*W) | ㎡/Roll |
| 3/4" | 20 | 10 × 1 | 10 |
| 1" | 25 | 8 × 1 | 8 |
Main material: ULT—alkadiene polymer; color in Blue | LT—NBR/PVC; color in Black
With 5 large automatic assembly lines, more than 600,000 cubic meters of annual production capacity, our production facility is specified as the designated production enterprise of thermal insulation materials for the National energy department, Ministry of electric power and Ministry of Chemical industry. We have been invited to participate in many related exhibitions at home and abroad. These exhibitions give us the opportunity to meet more and more friends and customers in related industries. Welcome all the friends to come and visit our factory!
| Property | Base material | Standard / Test Method | |
|---|---|---|---|
| Kingflex ULT | Kingflex LT | ||
| Thermal Conductivity |
-100°C, 0.028 -165°C, 0.021 |
0°C, 0.033 -50°C, 0.028 |
ASTM C177 |
| Density Range | 60-80Kg/m³ | 40-60Kg/m³ | ASTM D1622 |
| Recommend Operation Temperature | -200°C to 125°C | -50°C to 105°C | - |
| Percentage Of Close Areas | >95% | >95% | ASTM D2856 |
| Moisture Performance Factor | NA | <1.96x10⁻¹¹g/(m·s·Pa) | ASTM E 96 |
| Wet resistance Factor μ | NA | >10000 | EN12086 / EN13469 |
| Water Vapor Permeability Coefficient | NA | 0.0039g/h.m² (25mm thickness) | ASTM E 96 |
| PH | ≥8.0 | ≥8.0 | ASTM C871 |
| Tensile Strength Mpa |
-100°C, 0.30 -165°C, 0.25 |
0°C, 0.15 -50°C, 0.218 |
ASTM D1623 |
| Compressive Strength Mpa | -100°C, ≤0.3 | -40°C, ≤0.16 | ASTM D1621 |
The flexible ultra-low temperature adiabatic system features inherent impact resistance. Its cryogenic elastomer material effectively absorbs external machinery vibrations and impacts to protect the core system structure.
Equipped with a built-in vapor barrier, this product substantially extends the operating life of the entire cold insulation system while reducing the risk of sub-insulation pipe corrosion.
The flexible ULT insulation system eliminates the need for additional fiber materials as expansion and contraction fillers due to its integrated expansion joint design.
Kingflex ULT uses alkadiene polymer (Blue in color) as its base material, while Kingflex LT is composed of NBR/PVC (Black in color).
The recommended operating temperature for Kingflex ULT is from -200°C to 125°C, making it suitable for ultra-low temperature environments. The recommended range for Kingflex LT is -50°C to 105°C.
The system features a built-in vapor barrier that prevents moisture ingress, significantly extending the lifespan of the cold insulation and mitigating the risk of corrosion under insulation (CUI).
No, the built-in expansion joint feature removes the necessity for auxiliary fiber materials to handle expansion and contraction movements.
According to ASTM C177 test standards, the thermal conductivity of Kingflex ULT is 0.028 W/(m·K) at -100°C and 0.021 W/(m·K) at -165°C.
Our facility houses 5 large-scale automatic assembly lines, providing an annual production capacity exceeding 600,000 cubic meters.
