Kingflex
Kingflex
| Property | Base material | Standard / Test Method | |
|---|---|---|---|
| Kingflex ULT | Kingflex LT | ||
| Thermal Conductivity | -100°C, 0.028 -165°C, 0.021 |
0°C, 0.033 -50°C, 0.028 |
ASTM C177 |
| Density Range | 60-80Kg/m³ | 40-60Kg/m³ | ASTM D1622 |
| Recommend Operation Temperature | -200°C to 125°C | -50°C to 105°C | - |
| Percentage Of Close Areas | >95% | >95% | ASTM D2856 |
| Moisture Performance Factor | NA | <1.96x10⁻¹¹g/(m·s·Pa) | ASTM E 96 |
| Wet resistance Factor μ | NA | >10000 | EN12086 EN13469 |
| Water Vapor Permeability Coefficient | NA | 0.0039g/h.m² (25mm thickness) |
ASTM E 96 |
| PH | ≥8.0 | ≥8.0 | ASTM C871 |
| Tensile Strength Mpa | -100°C, 0.30 -165°C, 0.25 |
0°C, 0.15 -50°C, 0.218 |
ASTM D1623 |
| Compressive Strength Mpa | -100°C, ≤0.3 | -40°C, ≤0.16 | ASTM D1621 |
Application: Liquefied natural gas (LNG), pipelines, petrochemicals industry, industrial gases, and agricultural chemicals and other piping and equipment insulation project and other heat insulation of cryogenic environment.
| Kingflex Dimension | |||
|---|---|---|---|
| Inches | mm | Size (L * W) | ㎡ / Roll |
| 3/4" | 20 | 10 × 1 | 10 |
| 1" | 25 | 8 × 1 | 8 |
These materials are designed for piping and equipment insulation in cryogenic environments, including liquefied natural gas (LNG) facilities, petrochemical plants, industrial gas pipelines, and agricultural chemical piping.
Kingflex ULT is suitable for extreme cryogenic conditions ranging from -200°C to 125°C. Kingflex LT is designed for moderate low-temperature applications ranging from -50°C to 105°C.
Both products have a closed-cell area percentage greater than 95% (tested under ASTM D2856). This tight structure prevents water vapor ingress and ensures long-term stable thermal efficiency.
According to ASTM C177 test standard, Kingflex ULT features a thermal conductivity of 0.028 W/(m·K) at -100°C, and drops to 0.021 W/(m·K) at -165°C.
Standard options include a 3/4" (20mm) thickness roll measuring 10m × 1m (10 ㎡/roll) and a 1" (25mm) thickness roll measuring 8m × 1m (8 ㎡/roll).
