The material and honeycomb structure of this flexible insulation are manufactured in accordance with the appropriate density (7500) and closed cell ratio to ensure long-term insulation efficiency and resistance to water vapor permeability.
💡
Products include Thermal Insulation, Sound Insulation, Adhesive insulation series, and so on. They are widely used in the industry of Construction, Vehicle, Chemical storage and Transportation.
| Dimension Specifications |
| Thickness |
Width 1m |
Width 1.2m |
Width 1.5m |
| Inches |
mm |
Size (L*W) |
㎡/Roll |
Size (L*W) |
㎡/Roll |
Size (L*W) |
㎡/Roll |
| 1/4" |
6 |
30 × 1 |
30 |
30 × 1.2 |
36 |
30 × 1.5 |
45 |
| 3/8" |
10 |
20 × 1 |
20 |
20 × 1.2 |
24 |
20 × 1.5 |
30 |
| 1/2" |
13 |
15 × 1 |
15 |
15 × 1.2 |
18 |
15 × 1.5 |
22.5 |
| 3/4" |
19 |
10 × 1 |
10 |
10 × 1.2 |
12 |
10 × 1.5 |
15 |
| 1" |
25 |
8 × 1 |
8 |
8 × 1.2 |
9.6 |
8 × 1.5 |
12 |
| 1 1/4" |
32 |
6 × 1 |
6 |
6 × 1.2 |
7.2 |
6 × 1.5 |
9 |
| 1 1/2" |
40 |
5 × 1 |
5 |
5 × 1.2 |
6 |
5 × 1.5 |
7.5 |
| 2" |
50 |
4 × 1 |
4 |
4 × 1.2 |
4.8 |
4 × 1.5 |
6 |
| Technical Specifications |
| Property |
Unit |
Value |
Test Method |
| Temperature range |
°C |
(-50 - 110) |
GB/T 17794-1999 |
| Density range |
Kg/m³ |
45-65Kg/m³ |
ASTM D1667 |
| Water vapor permeability |
Kg/(m.s.pa) |
≤0.91×10⁻¹³ |
DIN 52 615 / BS 4370 Part 2 1973 |
| μ |
- |
≥10000 |
- |
| Thermal Conductivity |
W/(m.k) |
≤0.030 (-20°C) |
ASTM C 518 |
| ≤0.032 (0°C) |
| ≤0.036 (40°C) |
| Fire Rating |
- |
Class 0 & Class 1 |
BS 476 Part 6 part 7 |
| Flame Spread and Smoke Developed Index |
- |
25/50 |
ASTM E 84 |
| Oxygen Index |
- |
≥36 |
GB/T 2406, ISO4589 |
| Water Absorption, % by Volume |
% |
20% |
ASTM C 209 |
| Dimension Stability |
- |
≤5 |
ASTM C534 |
| Fungi resistance |
- |
Good |
ASTM 21 |
| Ozone resistance |
Good |
GB/T 7762-1987 |
| Resistance to U.V. and weather |
Good |
ASTM G23 |
We have the most advanced technology, with an experienced and professional team. We aim to provide High Quality Products and the Best Service that beyond what you expect. This flexible insulation material is becoming more and more popular for its durability, safety and environmental protection. Our teams strive to provide High Quality Energy Saving Material to the whole world, to create a Green and Environmentally protected Beautiful Home for you.
The elastic rubber foam features high fire resistance. In the event of a fire, it does not allow the flame to spread in the vertical and horizontal directions. With this function, it meets all the values of fire safety regulations and is an insulating material that you can use in buildings and facilities with confidence. This elastic rubber foam insulation is rubber-based, has a smooth cell structure with closed cells, and is produced in the form of sheets and tubes.
Frequently Asked Questions (FAQ)
What are the primary applications of this elastic rubber foam?
This material is widely utilized across various sectors including building construction, automotive engineering, chemical storage facilities, and transport piping systems for effective thermal and acoustic insulation.
How does the insulation material perform in fire conditions?
The material is engineered with strong fire resistance properties (Class 0 & Class 1 rating). In the event of a fire, it prevents the horizontal and vertical propagation of flames, meeting strict international safety compliance codes.
What temperature range can this insulation support?
It functions efficiently within a temperature operating range from -50°C up to 110°C, making it suitable for both cooling systems and heating piping insulation.
How does the closed-cell structure improve moisture resistance?
The closed-cell honeycomb structure ensures exceptionally high resistance to water vapor permeability (μ ≥ 10000), which protects piping from condensation and prevents long-term moisture accumulation.
Is the insulation material resistant to environmental factors?
Yes, technical tests show that the material offers excellent resistance to fungal growth, ozone degradation, and continuous ultraviolet (UV) weathering, ensuring long-term durability.
What product forms and size configurations are available?
The rubber foam insulation is manufactured in both sheets and tubes, with standard thickness ranging from 1/4" to 2" and widths available in 1m, 1.2m, and 1.5m rolls.
