| Technical Data Sheet | |||
|---|---|---|---|
| Property | Unit | Value | Test Method |
| Temperature range | °C | -50 to 110 | GB/T 17794-1999 |
| Density range | Kg/m³ | 45-65 | ASTM D1667 |
| Water vapor permeability | Kg/(m·s·Pa) | ≤0.91×10⁻¹³ | DIN 52 615 / BS 4370 Part 2 1973 |
| μ (Water Vapor Resistance Factor) | - | ≥10000 | - |
| Thermal Conductivity | W/(m·K) |
≤0.030 (-20°C) ≤0.032 (0°C) ≤0.036 (40°C) |
ASTM C 518 |
| Fire Rating | - | Class 0 & Class 1 | BS 476 Part 6 & Part 7 |
| Flame Spread and Smoke Developed Index | - | 25/50 | ASTM E 84 |
| Oxygen Index | - | ≥36 | GB/T 2406, ISO4589 |
| Water Absorption, % by Volume | % | 20% | ASTM C 209 |
| Dimension Stability | % | ≤5 | ASTM C534 |
| Fungi resistance | - | Good | ASTM G21 |
| Ozone resistance | - | Good | GB/T 7762-1987 |
| Resistance to U.V. and weather | - | Good | ASTM G23 |
The high density and closed structure of selected raw materials provides extremely low thermal conductivity and stable temperature control, delivering an excellent isolation effect for both hot and cold media.
When exposed to fire, the insulation material does not melt, produces minimal smoke, and prevents flame spread to guarantee safety. The material is classified as nonflammable, with an operating temperature range of -50℃ to 110℃.
The environmentally safe raw material causes no irritation or pollution, posing no hazard to health or the environment. It actively prevents mold growth and rodent damage while offering outstanding resistance to corrosion, acids, and alkalis for an extended service life.
Installation is simple and convenient. There is no need for extra auxiliary layers; the material can be cut and adhered directly, which significantly reduces manual labor and installation time.
The material is engineered to perform reliably across a wide temperature range, specifically from -50°C to 110°C, making it suitable for both cold and hot media isolation.
This product achieves Class 0 and Class 1 ratings when tested under BS 476 Part 6 & Part 7. Additionally, it has a Flame Spread and Smoke Developed Index of 25/50 in compliance with ASTM E 84, demonstrating excellent fire retardant capabilities.
Yes. The material is manufactured with eco-friendly raw substances that release no pollution or harmful elements. It prevents mold development and rodent damage while resisting acid, alkali, and environmental weathering.
It features a highly effective moisture barrier with a water vapor permeability rating of ≤0.91×10⁻¹³ Kg/(m·s·Pa) and a resistance factor (μ) of ≥10000, ensuring long-term thermal efficiency.
No. The insulation is designed for easy installation without the need for complex auxiliary structures. You simply cut to the desired size and bond the seams together, reducing labor overhead.
