China Kingflex Colorful NBR PVC Rubber Foam Sheet Roll Manufacturer, Supplier

1 / 1

China Kingflex Colorful NBR PVC Rubber Foam Sheet Roll Manufacturer, Supplier

Kingflex colorful rubber foam insulation products widely used in different functional distinctions.

Send Inquiry

Product Description

Kingfle colorful rubber foam sheet are commonly used for a variety of purposes, including insulation, cushioning, and protection. The foam material provides a soft and lightweight option for covering or padding objects. Foam sheet can be used to insulate pipes, preventing heat loss and condensation buildup. The colored variations can help differentiate between different pipe systems, such as hot and cold water pipes.

Kingflex Dimension
Thickness		Width 1m		Width 1.2m		Width 1.5m
Inches	mm	Size(L*W)	㎡/Roll	Size(L*W)	㎡/Roll	Size(L*W)	㎡/Roll
1/4"	6	30 × 1	30	30 × 1.2	36	30 × 1.5	45
3/8"	10	20 × 1	20	20 × 1.2	24	20 × 1.5	30
1/2"	13	15 × 1	15	15 × 1.2	18	15 × 1.5	22.5
3/4"	19	10 × 1	10	10 × 1.2	12	10 × 1.5	15
1"	25	8 × 1	8	8 × 1.2	9.6	8 × 1.5	12
1 1/4"	32	6 × 1	6	6 × 1.2	7.2	6 × 1.5	9
1 1/2"	40	5 × 1	5	5 × 1.2	6	5 × 1.5	7.5
2"	50	4 × 1	4	4 × 1.2	4.8	4 × 1.5	6

Kingflex colored rubber foam sheet features

✓ The product is inflammable and has high safety performance.
✓ Flexible material, suitable for various shapes and easy installation.
✓ The closed cell structure prevents the penetration of water vapor and prolongs the service life.
✓ Beautiful Appearance.
✓ Safety and Environmental Protection.

Kingflex Technical Data
Property	Unit	Value	Test Method
Temperature range	°C	(-50 - 110)	GB/T 17794-1999
Density range	Kg/m3	45-65Kg/m3	ASTM D1667
Water vapor permeability	Kg/(m.s.pa)	≤0.91×10 ﹣¹³	DIN 52 615 / BS 4370 Part 2 1973
μ	-	≥10000
Thermal Conductivity	W/(m.k)	≤0.030 (-20°C)	ASTM C 518
		≤0.032 (0°C)
		≤0.036 (40°C)
Fire Rating	-	Class 0 & Class 1	BS 476 Part 6 part 7
Flame Spread and Smoke Developed Index		25/50	ASTM E 84
Oxygen Index		≥36	GB/T 2406,ISO4589
Water Absorption,%by Volume	%	20%	ASTM C 209
Dimension Stability		≤5	ASTM C534
Fungi resistance	-	Good	ASTM 21
Ozone resistance		Good	GB/T 7762-1987
Resistance to U.V. and weather		Good	ASTM G23

Frequently Asked Questions (FAQ)

What are the primary applications of Kingflex colorful rubber foam sheets?

They are commonly used for insulation, cushioning, and protection. Specifically, they provide a lightweight, soft cover for padding objects and are widely utilized to insulate hot and cold water pipes to prevent condensation and heat loss.

What temperature range can this rubber foam sheet withstand?

According to the technical testing standard GB/T 17794-1999, the stable operating temperature range for the material is from -50°C to 110°C.

Does the product offer good fire safety ratings?

Yes. The product features highly rated fire-resistant properties, achieving Class 0 & Class 1 ratings when tested under BS 476 Part 6 & Part 7, and a flame spread/smoke developed index of 25/50 under ASTM E 84.

What is the advantage of the closed cell structure?

The closed cell design blocks water vapor penetration (permeability ≤0.91×10 ﹣¹³ Kg/(m.s.pa)), which dramatically slows degradation, prevents moisture buildup, and extends the long-term insulation life of the system.

What sizes and thicknesses are available for purchase?

Sheets come in thicknesses ranging from 1/4" (6mm) up to 2" (50mm). Roll options are available in standard widths of 1m, 1.2m, and 1.5m to fit various industrial or residential project needs.

Is the insulation material resistant to environmental factors like UV and ozone?

Yes, technical evaluations show the foam has "Good" rating levels for fungi resistance (ASTM 21), ozone resistance (GB/T 7762-1987), and resistance to UV and weathering (ASTM G23).
