Product Description

Insulation Application Gallery 1
Insulation Application Gallery 2
Insulation Application Gallery 3
Insulation Application Gallery 4
Insulation Application Gallery 5
Reliably insulates LNG storage tanks, fuel tanks and pipe systems and thus, contributes towards the efficiency, durability and reliability of these applications.
Insulation Detail View 1
Insulation Detail View 2

The flexible ultra-low temperature adiabatic system has the inherent characteristics of impact resistance, and its cryogenic elastomer material can absorb the impact and vibration energy caused by the external machine to protect the system structure.

Global demand for liquefied natural gas (LNG) is rising. High-performance technology is required for reliable transport and storage. Engineers have to develop plants that are safe and efficient. The extremely low temperature, at which natural gas is in a liquid state, places high demands on the technical infrastructure throughout the entire value chain of LNG. All the plant components and systems coming into contact with the liquefied gas have to be extremely well insulated.

Thermal Conductivity and Performance Chart
Technical Specifications
Thermal Conductivity
(0℃, 0.033; -50℃, 0.028)
Density
40-60 kg/m³
Recommended Temp
-50℃ to +105℃
Closed Cell Ratio
> 95%
Tensile Strength
(0℃, 0.15 MPa; -40℃, 0.218 MPa)
Compressive Strength
(-40℃, ≤0.16 MPa)
Testing and Lab Certification 1
Testing and Lab Certification 2
Testing and Lab Certification 3
Exhibition and Client Meeting 1
Exhibition and Client Meeting 2
Exhibition and Client Meeting 3
Exhibition and Client Meeting 4

Participation in many international exhibitions every year fosters long-term relationships with customers and industry partners from all over the world.

Growth in the construction and remodeling industries, combined with concerns over rising energy costs and noise pollution, are fueling market demand for thermal insulation. With over 40 years of dedicated experience in manufacturing and applications, specialized technical production sits at the forefront of the industry. Focusing on all verticals in the commercial and industrial market, scientists and engineers continuously roll out new products and applications to make living spaces more comfortable and businesses more profitable.

Frequently Asked Questions (FAQ)
Q: What applications is this flexible ultra-low temperature insulation system designed for?
A: This system is primarily designed to reliably insulate LNG storage tanks, fuel tanks, and piping systems, improving their overall efficiency, durability, and operational safety.
Q: How does the system handle impact and machine vibrations?
A: It features a cryogenic elastomer material with inherent impact-resistant properties. This material absorbs external mechanical impact and vibration energy to protect the overall structure.
Q: What is the recommended temperature range for this insulation?
A: The recommended operating temperature range for this high-performance insulation system is between -50℃ and +105℃.
Q: What is the cell structure and density of the material?
A: The material features a high closed-cell structure with a closed area ratio exceeding 95% and a density range of 40-60 kg/m³, which ensures stable thermal performance.
Q: What is the thermal conductivity of this insulation at sub-zero temperatures?
A: The thermal conductivity value is 0.033 W/(m·K) at 0℃, and drops to 0.028 W/(m·K) at -50℃, indicating excellent insulation efficiency at low temperatures.
Q: What are the mechanical strength properties under cold conditions?
A: The material has a tensile strength of 0.15 MPa at 0℃ (rising to 0.218 MPa at -40℃) and a compressive strength of ≤0.16 MPa at -40℃, ensuring high structural integrity in extreme cold.
